Spectra Geospatial RG3-S31-002 Ranger 3L Data Collector

Overview for Spectra Geospatial RG3-S31-002 Ranger 3L Data Collector

Designed for accuracy, functionality, and durability, the Spectra Ranger 3L Data Collector is a powerful tool for all field data collecting needs in surveying and construction. It is equipped with Bluetooth technology that offers a working range of up to 30 feet and allows easy connection to field equipment such as total stations and GNSS receivers. Featuring an integrated GPS receiver with enabled WAAS (Wide Area Augmentation System), a built-in compass, and an accelerometer, it has improved tracking and navigating capabilities.

Using a high-speed 800MHz processor and 256MB RAM, this data collector by Spectra can run demanding applications. Its Windows Mobile 6.5 Professional operating system supports various programs including Internet Explorer, Word, Excel, PowerPoint, Outlook, Media Player, and Adobe Reader. It comes with an 8GB flash memory for storing data and utilizes Wi-Fi connectivity, USB ports, and high-capacity SD card slot for easy data sharing. With an on-board data collection software, it ensures optimum efficiency.

The Spectra Ranger 3L Data Collector permits easy reading and data input with its dual-layer glass touchscreen display and full alphanumeric keypad. It is supplied with a rechargeable Li-Ion battery and can operate for up to 30 hours. Rated IP67, it resists dust and can withstand water immersion. It also complies with military standards for drops, vibration, humidity, and extreme temperatures guaranteeing superior durability for heavy-duty applications.

Configuration Options

The Spectra Ranger 3L Data Collector comes with various software package options to meet different surveying applications. Please select your preference from the menu above.

• RG3-G31-002: Survey Pro GNSS

Spectra Survey Pro GNSS shares nearly all the Survey Pro functions, and it provides the capability to collect data from RTK GNSS receivers – the most accurate worldwide GSP system there is, with centimeter-level accuracy. Survey Pro GNSS software is easy to use and has step-by-step features that reduce training and simplify setups. It provides error messages if anything goes wrong. All staking functions are supported in the GNSS module too.

• RG3-M31-002: Survey Pro Max

Spectra Survey Pro Max is the ultimate field software. It completely supports all instruments and has all the software features. It integrates Survey Pro Robotics and Survey Pro GNSS functions, enabling you to use the same job files with both GNSS receivers and total stations.

• RG3-P31-002: Survey Pro PRO

Spectra Survey Pro shares all the Survey Standard functions and adds advanced features. It provides intuitive and powerful slope staking and road layouts. You can also view DTM files, stake using the DTM surface and collect feature or attribute data, helping you save time in the field and in the office.

• RG3-R31-002: Survey Pro Robotics

Spectra Survey Pro Robotics shares all Survey Pro functions and reliably controls your robotic total station with an easy-to-use interface that features intuitive, useful search tools, active maps, automatic repetition and a fine-turning routine that lets you make even precise turns remotely.

• RG3-S31-002: Survey Pro Standard

Spectra Survey Pro Standard is the base model of Survey Pro software and is a complete data collection package for surveyors. It contains a complete COGO (Coordinate Geometry) suite including triangle solutions, map check and predetermined area, as well as traverse, sideshot and staking routines. It has all the essential features required to properly manage a survey job.
